Gravity Hinge Type Davit
Share to:
Gravity Hinge Type Davit

1、This davit conforms to the requirements of the Amendments to SOLAS 1996 --- MSC 47(66), International LSA Code MSC 48(66),IMO Resolution MSC81(70) and MSC.216(82), MSC.218(82) and MSC 226(82).

2、The davit is a gravity type davit and it lowers the boat on the water by its own weight.

3、The davit is designed for boarding the boat in stowed position. The boat could be lowered to the surface continuously and without stopping at the short time.

4、The boat is lowered by the remote control. The crew can release and stop the hand brake of the winch from inside of the boat via wire connection to the brake arm and wire spoil on the small drum. Alternatively the crew can operate the hand brake on the deck.

5、There is the fastening unit at the head and end of the lifeboat for fastening the boat and avoiding the lifeboat swaging on the wave.

6、The winch with the motor is used for recovering the lifeboat with 2 persons or rescue boat with 6 persons and back to the boardingdeck.
